Product Series
XL / SL Impurity and Slurry Pumps
Non-clogging impurity and slurry pumps for solid-liquid mixtures in paper, aquaculture, sewage and dredging applications.
Application scenarios
- Pulp and industrial short fibers
- Sewage and sludge
- Coal slurry and tailings
- River and pond dredging
- Shellfish and granular solid-liquid mixtures
Representative models
XL14-60XL20-72SL10-110SL16-140
Key features
- Open flow passage for better solids handling
- Simple and reliable structure
- Two-position oil seal design
- Powder-coated castings
- Designed for abrasive and mixed-media duty
Model Indication
XL 14 - 60 B / SL 10 - 110 B
- XL / SL: non-clogging impurity and slurry pump series code
- 14 / 10: hydraulic head in meters
- 60 / 110: flow rate
- B/C/D: belt drive, diesel engine direct drive or electric motor direct drive
Models
Photographed representative models
Click a model to view its photo angles, model description and corresponding parameter row. The full series table below keeps models without current photos for selection reference.
XL14-60
XL14-60 Non-Clogging Impurity Pump
Non-clogging impurity pump for pulp, sewage, sludge, mortar, slurry and short-fiber media.
View model details
SL10-110
SL10-110 Non-Clogging Impurity Pump
Impurity pump for granular solid-liquid mixtures as well as pulp, sludge and slurry media.
View model details
XL / SL series performance parameters
The brochure separates power requirements for pulp and mortar/slurry conditions.
| Series | Model | Speed (r/min) | Head (m) | Flow (t/h) | Suction range (m) | Power for pulp (kW) | Power for mortar (kW) |
|---|---|---|---|---|---|---|---|
| XL | XL14-60 | 1450 | 14 | 60 | 6 | 5.5 | 7.5 |
| XL | XL20-72 | 1750 | 20 | 72 | 6 | 11 | 15 |
| SL | SL10-110 | 980 | 10 | 110 | 8 | 7.5 | 11 |
| SL | SL16-140 | 1250 | 16 | 140 | 8 | 15 | 18.5 |
